Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in making construction machinery. They manufacture equipment like boom lifts, aerial lifts and manlifts. These kinds of machinery are designed to facilitate access to hard to reach places, large equipment, roofs and buildings, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also called OSHA refers to a power-driven endless belt. This belt only moves in one direction and contains steps or handholds or paltforms which are attached to the unit to be able to transport workers from every floor.
TB85
The TB85 man lift by Terex provides a max working height at 91 feet. The platform's max height reaches 85 feet, whilst the model's maximum width is 8.5 feet. The TB85 has dimensions that measure 9 inches wide and 9 feet, 1-inch high by 36 feet. This particular model provides a reach of 70 feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal reaching 75 degrees.
Terex TB100
The maximum height of Terex's TB100 man lift is 106 feet and the maximum height of the platform is 100 feet. The TB100 when stowed away, is roughly 8.5 feet wide by 9 feet high by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, while the max working height reaches 116 feet. The model is 9 feet, 4 inches high x 8 feet wide when stowed away. The TB110 provides a maximum width of 8 feet and a horizontal reach of 67 feet. This model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
